Optical Networking & Sensing
We propose methods and architecture to conduct measurements and optimize newly installed optical fiber line systems semi-automatically using integrated physics-aware technologies in a data center interconnection (DCI) transmission scenario. We demonstrate, for the first time, digital longitudinal monitoring
The NEC Labs America team Yaowen Li, Andrea D’Amico, Yue-Kai Huang, Philip Ji, Giacomo Borraccini, Ming-Fang Huang, Ezra Ip, Ting Wang & Yue Tian (Not pictured: Fatih Yaman) has arrived in San Diego, CA for OFC24! Our team will be speaking and presenting throughout the event. Read more for an overview
We report the first field demonstration of 4D link tomography using a commercial transponder, which offers distance, time, frequency, and polarization-resolved monitoring. This scheme enables autonomous transponders that identify locations of multiple QoT degradation causes.
We introduce a novel scheme to detect and localize optical network anomaly using forward transmission sensing, and develop a heuristic algorithm to optimize the route selection. The performance is verified via simulations and network experiments.
A method is proposed in order to improve QoT-E by calibrating the physical model parameters of an optical link post-installation, using only total power monitors integrated into the EDFAs and an OSA at the receiver.
We proposed the use of BOTDA as a monitoring tool to identify fiber types present in deployed hybrid-span fiber cables, to assist in network planning, setting optimal launch powers, and selecting correct modulation formats.
We implement a cascaded learning framework using component-level EDFA models for optical power spectrum prediction in multi-span networks, achieving a mean absolute error of 0.17 dB across 6 spans and 12 EDFAs with only one-shot measurement.
We propose a method to estimate the input power dependency of the transceiver BER-OSNR characteristic. Experiments using commercial transceivers show that estimation error in Q-factor is less than 0.2 dB.
Recent advances in optical fiber sensing have enabled telecom network operators to monitor their fiber infrastructure while generating new revenue in various application scenarios, including data center interconnect, public safety, smart cities, and seismic monitoring. However, given the high utilization
There are increasing requirements for data center interconnection (DCI) services, which use fiber to connect any DC distributed in a metro area and quickly establish high-capacity optical paths between cloud services and mobile edge computing and the users. In such networks, coherent transceivers with
We report significant noise reduction in distributed acoustic sensing (DAS) link using enhanced-scatter fibre (ESF). The longest reach of 195km DAS link without inline amplifications is also demonstrated. We further present demonstration of simultaneous fibre-optic sensing and 400Gb/s data transmissions
We demonstrated under six minutes automatic provisioning of optical paths over field- deployed alien access links and WDM carrier links using commercial-grade ROADMs, whitebox mux-ponders, and multi-vendor transceivers. With channel probing, transfer learning, and Gaussian noise model, we achieved an
Coexistence of real-time constant-amplitude distributed acoustic sensing (DAS) and 400GbE signals is verified by field trial over metro fibers, demonstrating no QoT impact during co-propagation and supporting preemptive DAS-informed optical path switching before link failure
We report the first distributed acoustic sensing (DAS) experiment with over >1,000 km reach on a hybrid link comprising of a mixture of field and lab fibers with bi-directional inline Raman amplification after each span. We used 20× frequency-diversity chirped-pulses for the probe signal,and recovered
We present a manhole localization method based on distributed fiber optic sensing and weakly supervised machine learning techniques. For the first time to our knowledge, ambient environment data is used for underground cable mapping with the promise of enhancing operational efficiency and reducing field
We review recent advances in distributed fiber optic sensing (DFOS) and their applications. The scattering mechanisms in glass, which are exploited for reflectometry-based DFOS, are Rayleigh, Brillouin, and Raman scatterings. These are sensitive to either strain and/or temperature, allowing optical fiber
Distributed fiber optic sensing systems use long section of optical fiber as the sensing media. Therefore, the fiber characteristics determines the sensing capability and performance. In this presentation, various types of specialty optical fibers and their sensing applications will be introduced and
We explore two fiber sensing methods which enables coexistence with data transmission on DWDM fiber networks. Vibration detection and localization can be achieved by extracting optical phase from modified coherent transponders. Frequency-diverse chirped-pulse DAS with all-Raman amplification can improve
We review recent advances aimed at increasing the reach of distributed fiber optic sensing with simultaneous data transmission. We review two methods based on measurement of accumulated phase on telecom signals, and chirp-pulsed DAS with inline amplification and frequency diversity.
We review multiple use cases over deployed networks including co-existing sensing/data transmission, cable cut prevention and perimeter intrusion detection to realize telecom infrastructure can be sensing backbones instead of the sole function of data transmission.
We demonstrate distributed acoustic sensing (DAS) over a bidirectional datacenter link which uses self-homodyne coherent detection for the data signal. Frequency multiplexing allows sharing the optoelectronic hardware, and enables DAS as an auxiliary function.
We report the first distributed acoustic sensing (DAS) results over>1,000 km on a field-lab hybrid link using chirped-pulses with correlation detection and 20× frequency-diversity, achieving a sensitivity of 100 pa/√Hz at 20-meters spatial resolution.
We demonstrate a vibration detection and localization scheme based on bidirectional transmission of telecom signals with digital coherent detection at the receivers. Optical phase is extracted from the digital signal processing blocks of the coherent receiver, from which the vibration component is extracted
Distributed fiber optic sensing (DFOS) is a rapidly evolving field that allows the existing optical fiber infrastructure for telecommunications to be reused for wide-area sensing. Using the backscattering mechanisms of glass—which includes Rayleigh, Brillouin, and Raman backscatter—it is possible
We demonstrate, for the first time, that cyclic linear pulse coding can be bipolar for BOTDA sensors, breaking the unipolar limitation of linear coding techniques and elevating the coding gain for a given code length.
We demonstrate vibration detection and localization based on extracting optical phase from the DSP elements of a coherent receiver in bidirectional WDM transmission of 200-Gb/s DP-16QAM over 380 km of installed field fiber.
Distributed fiber optical systems (DFOS) allow deployed optical cables to monitor the ambient environment over wide geographic area. We review recent field trial results, and show how DFOS can be made compatible with passive optical networks (PONs).
We demonstrate a passive optical network (PON) that employs reflective semiconductor optical amplifiers (RSOAs) at optical network units (ONUs) to allow simultaneous data transmission with distributed fiber-optic sensing (DFOS) on individual distribution fibers.
To the best of our knowledge, we present the first field trial of distributed fiber optical sensing (DFOS) and high-speed communication, comprising a coexisting system, over an operation telecom network. Using probabilistic-shaped (PS) DP-144QAM, a 36.8 Tb/s with an 8.28-b/s/Hz spectral efficiency (SE)
An artificial neural network (ANN) based transfer learning model is built for quality of transmission (QoT) prediction in optical systems feasible with different modulation formats. Knowledge learned from one optical system can be transferred to a similar optical system by adjusting weights in ANN hidden
A two-stage neural network model is applied on captured PS-144QAM raw data to estimate channel G-OSNR in a metro network field trial. We obtained 0.27dB RMSE with first-stage CNN classifier and second-stage ANN regressions.
For the first time, we demonstrate detection of vehicle speed, density, and road conditions using deployed fiber carrying high-speed data transmission, and prove carriers’ large-scale fiber infrastructures can also be used as ubiquitous sensing networks.
We demonstrate high spectral efficiency transmission over 549 km of field-deployed single-mode fiber using probabilistic-shaped 144QAM. We achieved 41.5 Tb/s over the C-band at a spectral efficiency of 9.02 b/s/Hz using 32-Gbaud channels at a channel spacing of 33.33 GHz, and 38.1 Tb/s at a spectral
We propose a single-ended Brillouin-based sensor in elliptical-core few-mode optical fiber for multi-parameter measurement using spontaneous Brillouin scattering. Distributed sensing of temperature and strain is demonstrated over 0.5 km elliptical-core few-mode fiber.
We study digital signal processing techniques to optimize the back-to-back performance of large probabilistic shaped constellations. We cover joint optimization of LDPC and constellation shaping, CD pre-compensation, clipping and I/Q imbalance compensation.
An ensemble learning algorithm is applied to enhance filtering tolerance of cascaded WSSs in open ROADM environment to demonstrate ~0.8dB Q-factor improvement over MLSE after transmitting over 3200km with 16 ROADMs.
Quality of transmission prediction for real-time mixed line-rate systems is realized using artificial neural network based transfer learning with SDN orchestrating. 0.42 dB accuracy is achieved with a 1000 to 20 reduction in training samples.
41.5-Tb/s over 549 km of deployed SSMF in Verizon’s network is achieved using probabilistic-shaped 144QAM to optimize throughput at ultra-fine granularity. This is the highest C-band only capacity and spectral efficiency in metro field environment.
