Optical Networking & Sensing
The NEC Labs America team Yaowen Li, Andrea D’Amico, Yue-Kai Huang, Philip Ji, Giacomo Borraccini, Ming-Fang Huang, Ezra Ip, Ting Wang & Yue Tian (Not pictured: Fatih Yaman) has arrived in San Diego, CA for OFC24! Our team will be speaking and presenting throughout the event. Read more for an overview
Dependence of EDFA gain shape on input power and input spectrum shape is modelled using a simple neural network-based architecture for amplifiers with different gains and output powers. The model can predict the gain within ±0.1 dB. Even though the model has good success predicting the performance of
Simultaneous phase and polarization sensing with span length resolution using the supervisory path is demonstrated. It is shown that by measuring polarization rotation matrix of the return paths, instead of monitoring only the state of polarization, location of the polarization disturbance can be determined
Polarization-based, multi-span sensing over a link with reflection-back circuits is demonstrated experimentally. By measuring rotation matrices instead of just monitoring polarization, a 35 dB extinction in localization is achieved regardless of the disturbance magnitude.
We report the first distributed acoustic sensing (DAS) experiment with over >1,000 km reach on a hybrid link comprising of a mixture of field and lab fibers with bi-directional inline Raman amplification after each span. We used 20× frequency-diversity chirped-pulses for the probe signal,and recovered
We explore two fiber sensing methods which enables coexistence with data transmission on DWDM fiber networks. Vibration detection and localization can be achieved by extracting optical phase from modified coherent transponders. Frequency-diverse chirped-pulse DAS with all-Raman amplification can improve
We report the first distributed acoustic sensing (DAS) results over>1,000 km on a field-lab hybrid link using chirped-pulses with correlation detection and 20× frequency-diversity, achieving a sensitivity of 100 pa/√Hz at 20-meters spatial resolution.
Neural networks (NNs) are attractive for nonlinear impairment compensation applications in communication systems, such as optical fiber nonlinearity, nonlinearity of driving amplifiers, and nonlinearity of semiconductor optical amplifiers. Without prior knowledge of the transmission link or the hardware
In optical communication systems, fibre nonlinearity is the major obstacle in increasing the transmission capacity. Typically, digital signal processing techniques and hardware are used to deal with optical communication signals, but increasing speed and computational complexity create challenges for
Guided acoustic Brillouin (GAWBS) noise is measured using a novel, homodyne measurement technique for four commonly used fibers in long-distance optical transmission systems. The measurements are made with single spans and then shown to be consistent with separate multi-span long-distance measurements.
Neural networks are attractive for nonlinear impairment compensation applications in communication systems. In this paper, several approaches to reduce computational complexity of the neural network-based algorithms are presented.
CCCE in a 60-km fiber is estimated from its GAWBS noise spectrum by comparing the TR 1m modes with the R 0m modes. The estimated CCCE value 0.73 μm is consistent with conventional measurements of 0.6–0.8 μm.
We demonstrate the experimental implementation of photonic neural network for fiber nonlinearity compensation over a 10,080 km trans-pacific transmission link. Q-factor improvement of 0.51 dB is achieved with only 0.06 dB lower than numerical simulations.
Fiber nonlinearity is one of the major limitations to the achievable capacity in long distance fiber optic transmission systems. Nonlinear impairments are determined by the signal pattern and the transmission system parameters. Deterministic algorithms based on approximating the nonlinear Schrodinger
Fiber nonlinearity is a major limitation on the achievable maximum capacity per fiber core. Digital signal processing (DSP) can be used directly to compensate nonlinear impairments, however with limited effectiveness. It is well known that fibers with higher chromatic dispersion (CD) reduce nonlinear
Neuron network (NN) is proposed to work together with perturbation-based nonlinearity compensation (NLC) algorithm by feeding with intra-channel cross-phase modulation (IXPM) and intra-channel four-wave mixing (IFWM) triplets. Without prior knowledge of the transmission link and signal pulse shaping/baudrate,
Flexible wavelength-multiplexing technique in backbone submarine networks has been deployed to accommodate the trend of variable-rate modulation formats. In this paper, we propose a new design of flexible-rate transponders in the scenario of flexible multiplexing scheme to achieve near-Shannon performance.
Asymmetric information is shown to be more accurate in characterizing the performance of quadrant folding shaped (QFS) M-QAM. The performance difference of QFS M-QAM schemes strongly depends on the FEC coding rate, and the optimum FEC coding rate is found to be around ?0.8, which is independent of QFS
An ensemble learning algorithm is applied to enhance filtering tolerance of cascaded WSSs in open ROADM environment to demonstrate ~0.8dB Q-factor improvement over MLSE after transmitting over 3200km with 16 ROADMs.
A simplified, system-agnostic NLC algorithm based on a neuron network is proposed to pre-distort symbols at transmitter side to demonstrate ~0.6dB Q improvement after 2800km SMF transmission using 32Gbaud DP-16QAM.
We report on the evolution of the longest segment of FASTER cable at 11,017 km, with 8QAM transponders at 4b/s/Hz spectral efficiency (SE) in service. With offline testing, 6 b/s/Hz is further demonstrated using probabilistically shaped 64QAM, and a novel, low complexity nonlinearity compensation technique
A novel algorithm to design geometric shaped 32QAM to work with probabilistic shaping is proposed to approach the Shannon limit within ~0.2 dB in SNR. The experimental results show ~0.2 dB SNR advantage over 64Gbaud PAS-64QAM, and flex-rate transmission demonstrates > 500 km reach improvement over 32QAM.
A systematic study, including theory, simulation and experiments, is carried out to review the generalized pairwise optimization algorithm for designing optimized constellation. In order to verify its effectiveness, the algorithm is applied in three testing cases: 2-dimensional 8 quadrature amplitude
Generalized mutual information (GMI) has been comprehensively studied in multidimensional constellation and probabilistic-shaped (PS) constellation together with different forward error correction (FEC) coding schemes. The simulation results confirm that GMI is an efficient and accurate tool to compare
